Name

Unit

Data

Main circuit

Rated working voltage (Ue)

kV

12

Rated working current (Ie)

A

160,200,250,400,630

Rated heat current (Ith)

A

160,200,250,400,630

Rated making capacity (I)

A

10Ie

Rated breaking capacity (Ic)

A

8Ie

Limit breaking capacity

A

10Ie

Rated short time withstand current and duration

A

10Ie/4

A/s

Control circuit

Rated voltage (Us) 1

V

AC.or DC.110/220

Rated power

(Ps)

Electric holding

VA

≯1000/100(attracting/holding)

Auxiliary circuit

Type

3a+2b

Rated value

380V/AC.5A or DC.1A

Rated operating frequency

Long time or mechanical holding type

Time/h

300

Short time

600

Mechanical life 2

10000time

100

Electric life

10000time

25(AC-3); 10(AC-4)

Remarks: 1 rated control voltage can be made according to the requirement of the user’s;
