Name

Unit

Data

Main

circuit

Rated working voltage (Ue)

kV

2

Rated working current (Ie)

A

1600

Rated thermal current (Ith)

A

1600

Rated making capacity (I)

A

1.5Ie

Rated breaking capacity (Ic)

A

1.5Ie

Control

circuit

Rated voltage (Us)1

V

DC.270

Rated power (Ps)

VA

≯15

Auxiliary circuit

type

3a+3b

Rated value

DC.270V

Rated operating frequency

Long time

Time/h

30

Short time

60

Mechanical life2

10000time

100

Electric life

10000time

25(AC-1)

Remark: 1 rated control voltage can be made according to the requirements of the user;
2 for mechanical holding type, interlock device should be replaced per 100,000 times.
